Active Audio SA300S+

Active Audio SA300S+ StepArray+ Self-powered DSP Column Loudspeaker DanteTM-enabled 3.00 m
Product code (SKU): 126902
Product code: ACT-SA300S+

Description

Dante™-compatible powered DSP column loudspeaker, 3.00m
For venues with raked seating
Designed for large-sized spaces with a 5 to 20° rake
Range: 36m at ±5dB

Acoustical data
Max SPL: 95dBSPL @ 20m
Range ±3dB: ±3dB 28m
Range ±5dB: ±5dB 36m
Angle of audience: 5°-20°
Frequency bandwidth: (-10dB) 110Hz-19kHz
Horizontal opening angle: 180°

Electrical data
Number of Channels: 6
Nominal impedance: 4Ω
Inputs: 1x sym. analog, 1x Dante™
Network: 1x RJ45Dante™

Mechanical data
Dimensions (WxPxH): 124mm x 159mm x 3005mm
Net / shipping weight: 29kg /33kg
Colors: white, black


StepArray+ Series: Overview

active audio step array plus series

About


StepArray+ is the latest range of column loudspeakers marketed by Active Audio.

With the advent of networked audio management, the aim is to offer an end-to-end solution of self-powered StepArray column loudspeakers compatible with market leader Dante™.

Therefore, the StepArray+ range has been pioneered which combines audio over IP with all the features of StepArray.

active audio steparray plus series sound

More flexibility and versatility with StepArray & Dante™

Ideal for:

Conference rooms

Public places

Houses of worships



Advantages

Superior intelligibility

Even sound coverage

Dante network compatibility

All-in-one solution

Easy maintenance

step array plus series technology

Technology - DGRC and Dante

StepArray+ column speakers enjoy the benefits of the two main current technologies for directivity control by implementing a hybrid principle patented by Active Audio: DGRC, digital and geometric radiation control.

With Dante™, Audinate has revolutionized how AV systems are connected. By transporting high-resolution signals over standard computer networks, Dante™ has finally brought affordability and reliability to audio over IP.

StepArray+ users will appreciate the sound performance achieved by the loss-free transmission of digital signals as well as the virtual absence of latency – less than one millisecond.

In addition to delivering pure performance, Dante™ provides superior flexibility and real-time diagnostics of the installation.

StepArray+ also supports the use of existing network cables and saves significant money on wiring with up to 64 channels over a single Ethernet cable.

StepArray+ combines the qualities of Dante™ and StepArray to raise the efficiency and flexibility bar even higher.

active audio step array plus series ICE power

Technology - ICEpower

By deciding to fit its StepArray+ column loudspeakers with ICEpower amplifier modules, Audio Active’s R&D team has chosen a well-known, controlled and robust technology.

ICEpower has already carved itself a solid reputation.

The Class D amplifier modules built into StepArray+ loudspeakers ensure superlative performance: their space-saving design and efficiency eliminate the problems generally experienced with embedded circuitry, namely weight, electricity use and heat generation.
