Configuration
Number of Conductors: 4
Product Line: Tini-QG
Mounting Type: Cord
Gender: Male
Contact Size: 24 AWG
Termination Style: Solder Cup
Contact Plating: Silver
Color: Nickel/Black
Locking: Locking
Handle Material: Thermoplastic
Packaging Type: Bulk
Standard Connector Type: Mini-XLR
Electrical
Contact Resistance: 0.01 Ohms
Dielectric Withstanding Voltage: 1000 Volts
Insulation Resistance: 510000 MOhms
Current Rating: 5 Amps
Mechanical
Coupling Locking Style: Button Latch
Wire Size: 28 AWG
Environmental
Humidity Rating: MIL-STD-202 Method 106D
Salt Spray: MIL-STD-202 Method 101
Mechanical Shock: MIL-STD-202 Method 213B
Vibration: MIL-STD-202 Method 201A
Maxiumum Temperature: 85 C
Compliance
RoHS Compliant: Compliant
REACH Compliant: Compliant
Brand: Switchcraft
Dimensional
Cable Opening: 0.13 in
Material
Body Material: Copper Alloy
Body Plating: Nickel
Contact Material: Copper Alloy
Contact Plating Type: Silver
Insert Material Type: Thermoplastic
Terminal Material: Steel
