Configuration
Number of Conductors: 5
Product Line: QG
Mounting Type: Cord
Mounting Feature: Chuck-Style Strain Relief
Gender: Female
Contact Size: 18 AWG
Termination Style: Solder Cup
Contact Plating: Silver
Color: Nickel
Locking: Locking
Handle Material: Zinc
Packaging Type: Bulk
Standard Connector Type: XLR
Electrical
Contact Resistance: 0.05 Ohms
Dielectric Withstanding Voltage: 1000 Volts
Insulation Resistance: 1000 MOhms
Current Rating: 7.5 Amps
Mechanical
Operating Force: 7 lbs
Coupling Locking Style: Button Latch
Environmental
Shielding: Shielded
Compliance
RoHS Compliant: Compliant
REACH Compliant: Compliant
Brand: Switchcraft
Dimensional
Cable Opening: 0.22 in
Material
Body Material: Copper Alloy
Body Plating: Nickel
Contact Material: Copper Alloy
Contact Plating Type: Silver
Insert Material Type: Molded Thermoplastic
Terminal Material: Copper Alloy Tinnned
