Configuration
Number of Conductors: 3
Mounting Type: Cord
Termination Style: Solder
Contact Plating: Gold
Color: Nickel
Locking: Locking
Sealed: Not Sealed
Handle Material: Brass
Packaging Type: Bulk
Number of Stations: 1
Standard Connector Type: 3.5mm Jacks & Plugs
Jack-Plug Type: Jack
Electrical
Contact Resistance: 0.02 Ohms
Dielectric Withstanding Voltage: 250 Volts
Insulation Resistance: 2000 MOhms
Circuit-Schematic: Double Open
Mechanical
Life Cycle: 5000 Cycles
Operating Force: 8 lbs
Coupling Locking Style: Threaded
Environmental
Shielding: Shielded
Mechanical Shock: MIL-STD-202F Method 107G
Vibration: MIL-STD-202F Method 201
Compliance
RoHS Compliant: Compliant
REACH Compliant: Compliant
Brand: Switchcraft
Dimensional
Cable Opening: 0.175 in
Material
Body Material: Brass
Body Plating: Nickel
Terminal Material: Copper Alloy
Spring Material: Beryllium Copper
