Dimensions at 20°C:
SVE5-3
High: 544 mm
Wide: 600 mm
Depth: 400 mm
Dimensional tolerance +2mm / -6mm
Material:
Body,SVE3, SVE4, SVE5-4 and SVE 5-3: LLDPE
Front-, back panel (when loose): PE-HD
Chemical resistance:
Fuels resistant
Acids resistant
Bases resistant
Salt Water resistant
UV-resistance
Tested acc. to DIN EN61439-1, Part1; subsection 10.2.4 resistance against UV radiation.
Tested at the UL International TTC GmbH, Krefeld, at the 17. 09.2010.
Project number: 666314_20100531_1
CHARPY test at 23°C, according to DIN EN ISO 179-1/1fA passed
Bending test at23°C, according to DIN EN ISO 178 passe
