Control buttons provide simple yet versatile control

The Octave Shift buttons – borrowed from Korg's MIDI controllers – allow the overall pitch to be shifted four levels, either UP or DOWN, in octave increments.

When used in conjunction with the Key Transpose feature, the nanoKEY2 can access the entire range of the notes in the MIDI spectrum.

For enhanced performances, the nanoKEY2 also provides Pitch Bend buttons, a Modulation button, and a Sustain button; one that's indispensible for piano or electric piano performance.

For each of these buttons, the on/off switching speed can be specified over four levels (using Korg Kontrol Editor), ensuring smooth changes that are appropriate for your performance.

USB power for an uncluttered setup

Just connect a single USB cable from your computer to the nanoKEY2, and you've got a quick and portable music production system. Power and USB-MIDI data travels down the same wire for a clean, efficient workspace.

Apple iPad Compatibility of nanoSERIES2

Using a USB cable to connect to the Apple Camera Connection Kit, Korg nanoSERIES2 controllers can be used with the iPad, without an external power supply.

You can enjoy iPad App like KORG iMS-20 along with nanoSERIES2.

Korg Control Editor software

The nanoKEY2 works with the "Korg Kontrol Editor" software – available for free download on the Korg website.

Load it into your computer, and use it to make detailed customized settings.

Choose from a total of four velocity settings: three velocity curves or fixed velocity; specify the control change messages transmitted by the modulation button and the sustain button

Specifications

• Controllers:

Keyboard: 25-key with velocity

Pitch up/down buttons

OCTAVE up/down buttons

MOD buttons

SUSTAIN buttons

• Octave Shift up/down buttons octave range: -4 to +4
• Velocity Curves: Four
• Corresponding Software: Host applications corresponding to MIDI input
• Connections: mini-USB
• Power: USB bus power
• Power Consumption: USB bus power - less than 100 mA
• Dimensions(W x D x H): 325mm x 83mm x 16 mm
• Weight: 244 g
• Accessories: USB cable
