Optical

• Light Source: 180 LEDs (36 red, 36 green, 36 blue, 36 amber, 36 lime) 2.5 W to 3.5, (725 mA)
• Color Temperature (range): 2800 to 6500 K
• CRI: 90
• Beam Angle (Horizontal): 111.4°
• Field Angle (Horizontal): 151.8°
• Beam Angle (Vertical): 76.7°
• Field Angle (Vertical): 134.4°
• Lumens: 19,575
• Illuminance (total): 280 lux @ 5 m PWM
• Frequency: 600, 1200, 2000, 4000, 6000, 25,000 Hz

Dynamic Effects

• Dimmer: Electronic
• Shutter/Strobe: Electronic
• Strobe Rate: 0 to 29 Hz
• Standalone Color Mixing: Yes
• Color Temperature Presets: Yes
• Dim Modes: 4
• Dim Curves: 4
• Built-in Automated Programs: Yes
• Customizable Programs: No
• Recall Custom Programs: No

Construction / Physical

• Dimensions: 1197 x 160 x 110 mm
• Weight: 11.2 kg
• Exterior Color: Black
• Housing Material: Aluminum die-cast

Certifications / Qualifications

• CE, MET, FCC, UKCA
• IP Rating: IP20, dry location
• Temperature (Ambient): -4 °F to 113 °F (-20 °C to 45 °C)

Control

• Protocol(s): DMX, RDM DMX
• Channels: 1, 3, 5, 7, 10, 12, 13, 16, 17, 33
• Modes/Personalities: 11 personalities (1, 3, 5, 7, 10, 12, 13, 16, 17, 33, HSV)

Connections

• Power Connection: Edison (Local) plug to Seetronic Powerkon IP65
• Power Input: Seetronic Powerkon IP65
• Power Output: Seetronic Powerkon IP65
• Data Connectors: 5-pin XLR
• Cable Length (power): 5 ft (1.5 m)

Electrical

• Input Voltage: 100 to 240 VAC, 50/60 Hz (auto-ranging)
• Power Linking: 4 units @ 120 V; 6 units @ 208 V; 7 units @ 230 V
• Power and Current: 345 W, 2.93 A @ 120 V, 60 Hz
• Power and Current: 338 W, 1.77 A @ 208 V, 60 Hz
• Power and Current: 334 W, 1.64 A @ 230 V, 50 Hz

What's Included

• OVATION CYC-3 FC
• Seetronic Powerkon power cord
• Omega brackets with mounting hardware

Optional Accessories

• Professional Clamps: CTC-50HC, CTC-50HCN
• Seetronic Powerkon power linking cables
• 3-pin or 5-pin DMX Cables
