CHAUVET Professional COLORado PXL Bar 16

CHAUVET Professional COLORado PXL Bar 16 Lighting Bar Pixel Wash 16 x 45W LED RGBW IP65 - Black

Variations

Call for pricing

Available

Product code (SKU): 122825

Product code: CHAPR-COLORADOPXLBAR16

Downloads

Description

COLORado PXL Bar 16 is a motorized, outdoor-ready tilting batten with zoom capabilities for creating bright, seamless, and pixel-mappable looks with advanced color and macro control.
Its versatile design is ideal for creating dynamic visual effects in touring, festival, and architectural applications, whether mounted on truss or positioned on the ground.
• Features sixteen 45W RGBW LEDs for intense, high-output pixel effects and washes.
• Offers a wide motorized zoom range of 5.8° to 47.9° for flexible beam shaping.
• Provides swift and quiet 200-degree motorized tilt for dynamic and precise positioning.
• Allows for full pixel mapping with individual control of all sixteen LEDs.
• Built with a rugged IP65-rated housing for reliable performance in any weather condition.
• Designed for seamless edge-to-edge mounting to maintain a consistent pixel pitch.

Based on your selection, you may be interested in the following items

CHAUVET Professional CTC-50G

CHAUVET Professional CTC-50G Gripper Clamp (50mm)

Available

Call for pricing

CHAUVET Professional UPLOAD 08

Available

Call for pricing

- 32 %

CHAUVET Professional RIGLINK Combo 5M

CHAUVET Professional RIGLINK Tr1 Dmx Combo Ip - 5M

Available 10 to 30 days

161,04 € 109,50 €

Details

COLORado PXL Bar 16 is a motorized, outdoor-ready tilting batten with capabilities to zoom for tight and wide pixel-mappable looks.

This bright, moving pixel bar also features seamless edge-to-edge mounting and includes virtual gobo and movement macros with separate foreground and background color control for more design options than ever before.

Slotted Omega brackets make it quick and easy to hang the fixture on truss.

The COLORado PXL Bar 16 can also be positioned on the ground, which allows for a variety of different light angles.

With two zones of control, the power is in your hands and the possibilities are endless!

Optical

Light Source: 16 LEDs (quad-color RGBW) 45 W, (3.0 A), 8875 K, 50,000 hours life expectancy
Color Temperature (calibrated white): 6122 K
CRI: 61.6
Beam Angle: 5.8° to 30.4°
Beam Angle single cell: 4° to 29.9
Field Angle: 8.9° to 42.2°
Field Angle single cell: 5.4° to 42.3°
Cutoff Angle: 10° to 47.9°
Cutoff Angle single cell: 6.1° to 45.5°
Zoom Range: 5.8° to 47.9°
Zoom Range single cell: 4° to 45.5°
Lumens (43.3°): 8,959
Illuminance (5.7°): 27,415 lux @ 5 m
Illuminance (43.3°): 1,294 lux @ 5 m
Selectable PWM: 600 Hz, 1,200 Hz, 2,000 Hz, 4,000 Hz, 6,000 Hz, 15,000 Hz

Dynamic Effects

Tilt: 200°
Tilt Ranges: 60°, 180°, 200°
Dimmer: Electronic
Shutter/Strobe: Electronic
Zoom: Motorized
Strobe Rate: 0 to 20 Hz
Dim Modes: 2
Dim Curves: 4

Construction / Physical

Dimensions: 39.37 x 5.47 x 10.75 in (1000 x 139 x 273 mm)
Weight: 45.6 lb (20.7 kg)
Exterior Color: Black
Housing Material: Aluminum alloy, Aluminum diecast, High-impact flame-retardant polymer

Certifications / Qualifications

CE, MET, FCC
IP Rating: IP65, temporary outdoor/wet use, with pressure equalizing M12 GORE valve
Temperature (Ambient): -4 °F to 113 °F (-20 °C to 45 °C)

Control

Control Protocol: Art-Net, Kling-Net, DMX, RDM, sACN

Connections

Power Connection: Bare end to Seetronic Powerkon IP65
Power Input: Seetronic Powerkon IP65
Power Output: Seetronic Powerkon IP65
Data Connectors: 5-pin IP rated, Seetronic IP rated RJ45 Connectors in/out
Cable Length (power): 5 ft (1.5 m)

Electrical

Input Voltage: 100 to 240 VAC, 50/60 Hz (auto-ranging)
Fuse: 12 A, 250 V
Power Linking: 0 unit @ 120 V; 3 units @ 208 V; 3 units @ 230 V
Power and Current: 790 W, 6.60 A @ 120 V, 60 Hz
Power and Current: 771 W, 3.821 A @ 208 V, 60 Hz
Power and Current: 768 W, 3.485 A @ 230 V, 50 Hz

Chauvet Professional COLORADO PXL BAR 16 included and Optional Accessories

What's Included

COLORado PXL Bar 16
Seetronic Powerkon IP65
2 Omega bracket with mounting hardware

Optional Accessories

Clamps
Neutrik powerCON cables
Neutrik etherCON cables
DMX Cables
Upload_08 software uploader
Flight cases
