Specifications

• DMX Channels: 8, 18, 34 or 47
• DMX Connectors: 5-pin XLR
• Light Source:

480 LEDs (tri-color) 2W, (1A), 50,000 hours life expectancy

32 LEDs (cool white) 1.8 W (0.5 A), 50,000 hours life expectancy

• Strobe Rate: 0 to 20 Hz
• Beam Angle: 119°
• Field Angle: 158°
• Illuminance: 1,131 lux @ 2 m
• Lumens: 13,626
• IP Rating: IP66
• Power Linking: 6 units @ 120 V; 11 units @ 230 V
• Input Voltage: 100 to 240 VAC, 50/60 Hz (auto-ranging)
• Power and Current:

238 W, 2 A @ 120 V, 60 Hz 231 W, 1 A @

230 V, 50 Hz

• Weight: 4.7 kg
• Size: 330 x 130 x 173 mm
• Approvals: CE, ROHS, MET
• Startup Temperature: -20 °C to 45 °C
• Operating Temperature: -30 °C to 45 °C
• Cable Length: 1.5 m
• Max Output Current: 12 A (6 units @ 120 V) (11 units @ 230 V)

What's included

• Shocker Panel FX IP
• Power cable
• Quick Reference Guide
