The iX12 is a two way full range compact loudspeaker designed for fixed installation purpose. The lo/mid section comprises a 12" cone driver installed in bass reflex.

The mid/hi section comprises a 1" HF driver. The iX12 is equipped with a set of high coaxial speakers which confers a perfectly coherent sound field with a conical dispersion of 90°. The APG iX12 loudspeaker is characterized by anti-diffraction baffle which allows it to have a excellent linearity. This results is a constant directivity. The iX12 is characterized by - SPL level / size - important, particularly extented bass, which provides high precision sound reproduction quality both in voice and music applications. The iX12 has an impedance of 8 ohms. She can also be integrated into line-type systems 70/100V transformer or 200W (T100/T200 option). Ergonomic, the iX12 offers all the functions and options suitable for fixed indoor installation : aesthetic trapezoidal format, Speakon connectors, baseplate. Metal inserts M8 allows its fixing by means of different accessories allowing horizontal, vertical mounting or adjusting the tilt of the enclosure. The reference iX12W is the white version. The iX12 can also be customized in color -iX12COL.

This rail allows multitude positions of adjustment in the vertical angle. Dedicated processor DMS48F, make it possible to protect and optimize the operation of the iX12 in full range mode or combined with subwoofer.

Technical features
Usable bandwidth(± 10 dB): 50 Hz - 20 kHz
SPL max @ 1m: 134 dB SPL (1)
Nominal directivity (H° x V°): 90° x 90° (2)
Nominal impedance: 8 ohm
Transducers: 1 x 12'' coaxial ventiled - 1 x 1,4'' HF ND driver
Topology: Coaxial - APG NDB Baffle
Type of load: Bass Reflex
Way and amplification section: 2 ways, mono amplified
AES power (W): 450 W (3)
Maximum power handling (W): 1800 W (4)
Dimensions H,W,D (mm): 15,7" x 23,5" x 13,4" (400 x 597 x 341 mm)
Weight (kg): 44 lb (20 kg)
Connectors: 2 x Speakon NL4MP
IP: 43
