Features & Benefits

Up to 37 A rms current rating
Unique Neutrik locking bushing and strain relief for cable diameters 10 mm to 16mm
IEC 61984, UL 1977 and CSA C22.2 No.182.3 certified
Superior NEUTRIK quality standard, extremely robust and reliable
Easy to assemble because the strain relief locks with the insert mechanically and aligns with the housing
Easy and reliable twist lock system
Ergonomic design with slip-proof two-component molded housing
Improved kink protection by two-component bushing

Electrical
Contact resistance: ? 2 mΩ
Dielectric strength: 2.8 kVac
Insulation resistance: > 10 GΩ (initially)
Number of electrical contacts: 4
Rating Europe: IEC 61984: 37 A 250 V AC
Rating USA: UL1977: 35 A 250 V AC
Rating Canada: CSA C22.2 No.182.3: 24 A 250 V AC

Attention This product is strictly not intended for use as an AC or DC power supply connector!
CAUTION: NOT FOR INTERRUPTING CURRENT

Mechanical
Cable O.D.: 10 - 16 mm
Lifetime typically: 5.000 mating cycles
Wiresize (mm²): 1.5 – 4 mm²
Wiresize (AWG): 17 – 11 AWG
Locking device: Twist lock
Termination: screw type terminals

Material
Contact plating: Ag
Contacts: Copper Alloy
Insert: Polyamide (PA6.6)
Locking element: Zinc diecast
Shell: Polyamide (PA6) / TPE
Strain relief: Polyketone
Bushing: Polypropylene / TPE

Environmental
Temperature range: -33 °C to +80 °C
Protection class: IP20
Flammability acc. to UL94: V-0
