Output

• Input voltage/frequency range: 180-240Vac 50-60 Hz
• Power Factor: PF >0.95
• Output channels: 64 (4 channels x 16 groups)
• Output voltage: 48 Vdc
• Output current: 700mA max (per channel)
• Max power: 2200 W

Distance between Drivenet and Projectors

• Max 100 m*

* Max projectors distance for FOS 100 and HELIOS R fixtrures must be 50 m FOS 100

Connections

• Output: Screw terminals connectors
• Mains: PowerCON male panel connector
• DMX: XLR 5-pole In/OUT and XLR 3-pole In/OUT panel connectors

Control

• Protocols: RDM / DMX 512
• Art-Net: Available on request
• Touch-screen color display
• Internal operating system updatable via DTS dongle firmware uploader

Physical

• IP rating: IP20
• 3-unit rack
• Weigth: 14.1 Kg (31.1 lbs)

Test and Cirtification

• CE

Accessories Included

• 1 x XLR 5 pins female cable connector (code 0508B065)
• 1 x XLR 5 pins male cable connector (code 0508B066)
• 1 x PowerCON female cable connector (code 0520P014)
