Output

• Lumen output: 10,800
• CRI: up to 98
• R9: up to 95
• TLCI: up to 96
• LED lifespan: 50000 hours (L70B10))

Optical Group

• Ø 250 mm Fresnel lens
• 10°- 47° linear zoom
• Indexable beam shaper (2:1 ratio) with endless continuous rotation
• Soft and heavy frost filter insertable via DMX
• Retractable ‘top hat’

Color/White Generation

• 6 color LED engine
• Linear CCT (1,800 K – 10,000 K)
• Green saturation: Linearly adjustable green/magenta point
• 100 gel filters emulation:

Linear crossfade from gel filters emulation to CCT whites

Linear crossfade between emulated gel filters

True color of gel filters emulation at any CCT values

• “Raw” RGBACL color-mixing in ‘Advanced’ mode
• Extra deep colors: Two DMX-selectable filters (‘deep blue’ and ‘deep red’) allow to further extend the range of reproducible colors toward the two ends of the visible spectrum
• HQS (High Quality Spectrum) – DTS trademark certifies a product’ superior white light quality and its ability to generate an extended color palette offering a wider gamut of pastel shades with rich warm nuances.

Control

• LCD graphic display with 4 soft keys (“auto-flip” and “key-lock” functions available)
• RDM / DMX 512 protocol, Art-Net 4, sACN protocols
• Wireless DMX available on request
• ‘Standard’ , ‘Silent’ operation modes.(automatic noise control up to the threshold of the operation modes)

Standard operation mode — dBA@1mt (100% lumen output power)

Silent operation mode 37 dBA@1mt (77% lumen out power)

• Firmware: Internal operating system updatable via DTS dongle firmware uploader
• “Li-Fe” backup battery allowing the use of the on-board unit display when it is not powered, besides ensuring a safe return and blockage of the top hat during shut down

Dimmer

• ‘Hi-Q Dimming’ technology – guarantees a perfect linearity in the increase / attenuation of brightness of multi-chip LED sources, even at low dimming levels, without visible ‘steps’ between adjacent values
• Tungsten emulation – CCT variation emulates behavior of Halo-lamps

DMX

• 5 DMX modes:

1. CCT (Default)

2. Advanced (Raw)

3. Basic

4. Expo

5. CMY Emulation

Pan & Tilt

• Pan 540° : 3.8 s
• Tilt 215° : 2.1 s
• 16-bit resolution
• Pan/Tilt Lock

Power Supply

• Electronic Wide-range 100/240 Vac 50-60 Hz
• Power consumption: 300 W max
• Power Factor: PF >0.94

Connections

• Power supply: PowerCON TRUE1 In/Out panel connectors
• DMX: XLR 3-pole and 5-pole In/Out panel connectors
• Art-Net / sACN: etherCON RJ45 connector

Circuits Protections

• Overvoltage and overtemperature circuit protection

Temperature

• Operating: -10° / 45°C
• Storage: -20° / 60°C

Physical

• Weight: 26,5 Kg (58 lbs)
• Finishing: Black
• IP20

Test and Certification

• CE

Accessories Included

• 1x powerCON TRUE1 female cable connector (code 0520P066)
• 2 x Omega bracket with “Fast Lock” connection 1/4 turn (code 02K00549)
• 1 x Alchemy 5 EZ-shell 560 x 490 x 670 mm – 2 pcs needed in each flightcase (code0512K152.1)

Accessories On Request

• Aliscaf clamp for tube diameter 48-51 mm – max. load. 200 Kg (code 0521A033)
• G-QUICK clamp Professional – max. load 100 Kg (code 0521A037)
• Flightcase for 2 units (code 0521C078)
• Outdoor DMX cable 2 x 0,25 mm2 – Flame retardant (code 0509C158)
• Safety cable 5 x 600 mm – Max load 60 Kg (code 0521A038)
• DTS firmware uploader dongle (code 03.LA.206)
