CHAUVET Professional Ovation CYC 1 FC

CHAUVET Professional Ovation CYC 1 FC Φωτιστικό Cyclorama Wash LED RGBAL IP20 - Μαύρο

Εναλλακτικά Χρώματα / Μεγέθη

Αμεσα Διαθέσιμο
Κωδικός (SKU): 119136
Κωδικός προϊόντος: CHAPR-OVATIONCYC1FCV2

Περιγραφή

A sleek and silent convection-cooled cyclorama fixture featuring an advanced RGBAL color-mixing system to deliver a wide, smooth, and richly saturated field of light.
Its fanless operation makes it ideal for theatrical and broadcast applications where silence is critical, while its low-profile design also allows for versatile use as a footlight.
• Features an advanced RGBAL engine for a full color spectrum with a high CRI.
• Provides precise beam control with an integrated kickstand and adjustable glare shield.
• Delivers exceptionally smooth fades with 16-bit dimming and four selectable curves.
• Adjustable PWM ensures flicker-free performance on camera for broadcast applications.
• Simplifies setup by power linking up to 11 units from a single 120 V source.
• Offers a virtual color wheel with presets that emulate popular gel colors.


Αναλυτικά


Ovation CYC 1 FC is an incredibly sleek, discreet, and light weight CYC that delivers a wide, smooth field of light with significant reach.

Completely convection cooled, the unit is ideal for applications where silent operation is critical.

Ovation Cyc 1 FC features the advanced RGBAL color-mixing system found in our other Full Color Ovation units to render nearly any color with tremendous realism and saturation.

Given the low-profile of the unit, it can also be used effectively as a footlight.

The versatile fixture has an integrated kick stand and included glare shield that can adjust and shape its throw and also features an included omega bracket.

Chauvet Professional Ovation CYC 1 FC optical

Optical

  • Light Source: 60 LEDs (12 red, 12 green, 12 blue, 12 amber, 12 lime) 1.75 to 4.57 W, (1.4 A), 6935 K, 50,000 hours life expectancy.
  • Color Temperature (range): 2800 to 6500 K
  • CRI: 90,6
  • Beam Angle (Horizontal): 81.1°
  • Field Angle (Horizontal): 124.6°
  • Beam Angle (Vertical): 87.1°
  • Field Angle (Vertical): 148.1°
  • Lumens: 8,966
  • Illuminance: 210 lux @ 5 m
  • Frequency: 600, 1200, 2000, 4000, 6000, 25,000 Hz
Chauvet Professional Ovation CYC 1 FC Dynamic Effects

Dynamic Effects

  • Dimmer: Electronic
  • Shutter/Strobe: Electronic
  • Strobe Rate: 0 to 27 Hz
  • Standalone Color Mixing: Yes
  • Color Temperature Presets: Yes
  • Dim Modes: 4
  • Built-in Automated Programs: Yes
  • Customizable Programs: No
  • Recall Custom Programs: No
Chauvet Professional Ovation CYC 1 FC Construction / Physical and certifications

Construction / Physical

  • Dimensions: 410 x 160 x 110 mm
  • Weight: 4,2 kg
  • Exterior Color: Black
  • Housing Material: Aluminum die-cast

Certifications / Qualifications

  • CE, MET, FCC
  • IP Rating: IP20, dry location
  • Temperature (Ambient): -4 °F to 113 °F (-20 °C to 45 °C)
Chauvet Professional Ovation CYC 1 FC control and connections

Control

  • Protocol(s): DMX, RDM
  • Channels: 2, 4, 5, 8, 11, 13, 14, 16 or HSV
  • Modes/Personalities: 9 personalities (2, 4, 5, 8, 11, 13, 14, 16 or HSV)

Connections

  • Power Connection: Edison (Local) plug to Seetronic Powerkon IP65
  • Power Input: Seetronic Powerkon IP65
  • Power Output: Seetronic Powerkon IP65
  • Data Connectors: 5-pin XLR
  • Cable Length (power): 5 ft (1.5 m)
Chauvet Professional Ovation CYC 1 FC electrical

Electrical

  • Input Voltage: 100 to 240 VAC, 50/60 Hz (auto-ranging)
  • Power Linking: 11 units @ 120 V; 21 units @ 208 V; 23 units @ 230 V
  • Power and Current: 139 W, 1.14 A @ 120 V, 60 Hz
  • Power and Current: 137 W, 0.64 A @ 208 V, 60 Hz
  • Power and Current: 137 W, 0.58 A @ 230 V, 50 Hz
Chauvet Professional Ovation CYC 1 FC included and Optional Accessories

What's Included

  • OVATION CYC-1FC
  • Seetronic Powerkon power cord
  • Omega brackets with mounting hardware

Optional Accessories

  • Professional Clamps: CTC-50HC, CTC-50HCN
  • Seetronic Powerkon power cables
  • 3-pin or 5-pin DMX Cables

Πληροφορίες και λήψεις

Manual
