Specifications
- DMX Channels: 8, 18, 34 or 47
- DMX Connectors: 5-pin XLR
- Light Source:
480 LEDs (tri-color) 2W, (1A), 50,000 hours life expectancy
32 LEDs (cool white) 1.8 W (0.5 A), 50,000 hours life expectancy
- Strobe Rate: 0 to 20 Hz
- Beam Angle: 119°
- Field Angle: 158°
- Illuminance: 1,131 lux @ 2 m
- Lumens: 13,626
- IP Rating: IP66
- Power Linking: 6 units @ 120 V; 11 units @ 230 V
- Input Voltage: 100 to 240 VAC, 50/60 Hz (auto-ranging)
- Power and Current:
238 W, 2 A @ 120 V, 60 Hz 231 W, 1 A @
230 V, 50 Hz
- Weight: 4.7 kg
- Size: 330 x 130 x 173 mm
- Approvals: CE, ROHS, MET
- Startup Temperature: -20 °C to 45 °C
- Operating Temperature: -30 °C to 45 °C
- Cable Length: 1.5 m
- Max Output Current: 12 A (6 units @ 120 V) (11 units @ 230 V)
