Specifications
- DMX Channels:2 or 9
- DMX Connectors:3-pin XLR
- Light Source:
(Kinta): 4 LEDs ( 1 Red, 1 Green, 1 Blue, 1 White) 7.5 W (2.4 A), 50,000 hours life expectancy
(Strobe): 16 SMD LEDs (white) 5 W (1.6 A) 50,000 hours life expectancy
(Laser): 650 nm/100 mW (Red) laser diode, 520 nm/30 mW (Green) laser diode
- Strobe Rate:0 to 20 Hz
- Coverage Angle:118°
- Power Linking:17 units @ 120 V; 33 units @ 230 V
- Input Voltage:100 to 240 VAC, 50/60 Hz (auto-ranging)
- Power and Current:
25 W, 0.5 A @ 120 V, 60 Hz
24 W, 0.2 A @ 230 V, 50 Hz
- Weight:3.8 lb (1.7 kg)
- Size:7.4 x 10.3 x 7.4 in (187 x 261 x 187 mm)
- Approvals:CE, FDA, RoHS, UKCA
- Optional Controllers: IRC-6
- Classified per EN/IEC 60825-1:2014
- Complies with FDA performance standards for laser products except for deviations pursuant to Laser Notice No. 56, dated May 8, 2019
