Specifications

• DMX Channels:8 or 14
• DMX Connectors:3-pin XLR
• Pan and Tilt:540°/270°
• Pan and Tilt Ranges:540°, 360°, 180° pan/270°, 180°, 90° tilt
• Colors:8 + white, split colors, continuous scroll at variable speeds
• Gobos:7 + open (6 aluminum + 1 glass), rotating, interchangeable, indexing, slot-n-lock, continuous scroll at variable speeds
• Light Source:1 LED (cool white) 100 W, (4.3 A), 50,000 hours life expectancy
• Strobe Rate:0 to 20 Hz
• Zoom Angle:12° to 17°
• Lumens:3,967
• Power Linking:5 units @ 120 V; 8 units @ 230 V
• Input Voltage:100 to 240 VAC, 50/60 Hz (auto-ranging)
• Power and Current:

217 W, 2.6 A @ 120 V, 60 Hz

211 W, 1.5 A @ 230 V, 50 Hz

• Gobo Size:24 mm outside, 20 mm image, 1.1 mm max thickness
• Weight:25 lb (11.4 kg)
• Size:12.7 x 8.7 x 16.7 in (322 x 220 x 423 mm)
• Approvals:CE, UKCA, RoHS, MET
• Color Temperature (CTO): 5,900 K
• Prism: 5-facet linear, bi-directional at variable speeds
• Prism: 3-facet round, bi-directional at variable speeds
• Illuminance:

(12°) : 41,601 lux @ 2 m

(17°) : 22,534 lux @ 2 m

• Optional Controllers: RFC, RFC-XL Max
• Output Current: 12 A (5 units @ 120 V) (8 units @ 230 V)

What's included

• Fixture
• Power cord
• Hanging bracket
• Quick Reference Guide
