Specifications
- DMX Channels: 2, 21, or 132
- DMX Connectors: 3-pin XLR
- Light Source:
pars: 6 LEDs (quad-color RGB + UV) 3.7 W 1A), 50,000 hours life expectancy
LED Strip: 74 LEDs (red, green, blue) 5 W (.03 A), 50,000 hours life expectancy
LED Strip: 74 LEDs (red, green, blue) 5 W (.03 A), 50,000 hours life expectancy
- Strobe Rate: 0 to 20 Hz
- Operating Frequency: 2.412 to 2.484 GHz
- Field Angle: 26°
- Illuminance: 3,872 lux @ 2 m
- Lumens: 1,938
- Power Linking: 11 units 120 V; 18 units 230 V
- Input Voltage: 100 to 240 VAC, 50/60 Hz (auto-ranging))
- Power and Current:
47 W, .7A 120 V, 60 Hz
47 W, .7A 120 V, 60 Hz
- Weight: 6 kg
- Size: 1047 x 94.5 x 272 mm
- Approvals: CE, ROHS, FCC
- Stand Height: 1.5 to 2.4 m
- Tripod leg widtth: 1.2 m
- Fits Tripod Size: 37.4 mm
- Beam Angle (pars): 13°
- Field Angle (pars): 24°
- Tripod leg widtth: 1.2 m
- Fits Tripod Size: 37.4 mm
- Cable Length: 2.844 m
- Foot Switch Operating Frequency: 433 MHz
- Foot Switch Max Unobstructed Distance: 30.5 m
- Footswitch battery: 9 V 300mA
- Optional Controllers: ILS Command, RF Remote
