Processing

Powerful Processing Every input has HPF, a super-fast gate with sidechain and filter, a musical 4-band parametric equaliser with RTA, and Peak/RMS compressor for control and shaping of levels and transients.

Mixes have both a parametric and 28 band graphic EQ along with compressor as standard, all ready to switch in when required.

FX

World-Class FX SQ is armed with 8 stereo FX engines and comes complete with the acclaimed RackExtra library, featuring emulations of legendary classic reverbs, gated reverbs, delays, modulators and more.

Every engine has its own dedicated stereo return too, so you don’t need to use up any of your 48 input channels.

Integrated USB Interface

Recored. Stream. Mix. SQ's built-in 32x32 96kHz audio interface enables easy multitrack recording, backing-track playback livestreaming and virtual soundcheck.

The interface is class-compliant on Mac OS X making it truly plug'n'play, with ASIO and WDM compatible drivers avaliable for Windows computers.

You can even map the SQ's faders, rotaries, channel keys and softkeys to control your favorite DAW using the Allen & Heath MIDI Control app.

Add-Ons

Take Your Mix to the Next Level Proven on countless world-tours with international artists, DEEP Processing and RackExtra FX from our award-winning dLive digital mixing system is now available within your SQ.

SQ-Driver

Record to USB The integrated SQ-Drive makes it quick and easy to capture and playback 16 channels (96kHz), 32 channels (48kHz), or a stereo recording of the performance direct to a USB key or drive. No software setup, no soundcard driver issues and no extra laptop to bring to the performance.

AMM

Automatic Mic Mixer SQ’s advanced automatic mic mixers (AMM’s) make it a natural choice for mixing conferences, panel talks and TV shows.

They’re fully integrated in the mixer too, with no extra latency, so you don’t need to route the audio to an internal DSP rack or an external plugin system.

Two fully independent 24 channel AMM’s can be utilised for two zones or combined into a single 48 channel AMM for larger events.

Features

• Audio and Processing:

96kHz XCVI FPGA processing

48 input channels

12 stereo mixes + LR

3 stereo matrix

8 stereo FX engines + dedicated stereo returns

• DEEP processing ready
• Onboard I/O:

32+1 built-in mic preamps

2 stereo line inputs

16 XLR line outputs

2 TRS line outputs AES output

Features

• Control:

32+1 Faders / 6 Layers

7” capacitive touchscreen

16 assignable SoftKeys

8 assignable Soft Rotaries

SQ-MixPad app

SQ4You app

• Expandability and Integration:

SLink port for remote audio / expansion

64×64 I/O port for audio networking cards (Dante, Waves, MADI, SLink)

• Recording and Streaming:

SQ-Drive direct recording to USB

32×32 96kHz USB interface
