Specifications

• DMX Channels: 9 or 15
• DMX Connectors: 3-pin XLR
• Pan and Tilt: 540°/229°
• Pan and Tilt Ranges: 180°, 360°, 540° pan/90°, 180°, 229° tilt
• Light Source: 1 LED (quad-color RGBW) 60 W, (4.4 A), 50,000 hours life expectancy
• Strobe Rate: 0 to 20 Hz
• Beam Angle: 12°
• Illuminance: 8,687 lux @ 2 m
• Power Linking: 7 units @ 120 V; 11 units @ 230 V
• Input Voltage: 100 to 240 VAC, 50/60 Hz (auto-ranging)
• Power and Current:

76 W, 1 A @ 120 V, 60 Hz

76 W, 0.7 A @ 230 V, 50 Hz

Specifications

• Gobos: 5 + open (6 glass), rotating, interchangeable, indexing, slot-n-lock, continuous scroll at variable speeds
• Gobo Size: 24 mm outside, 20 mm image, 1.1 mm max thickness
• Weight: 4.1 kg
• Size: 204 x 150 x 332 mm
• Approvals: CE, RoHS, FCC
• Optional Controllers: IRC-6, ILS Command

What's included

• Sentinel Spot Q60 ILS
• Power cord
• Hanging bracket
• Quick Reference Guide
